Rigaku Wins Diana Nyyssonen Memorial Best Paper Award with Method for Inspecting and Measuring Defects in 3D Flash Memory

(BUSINESS WIRE) -- Rigaku Corporation, a Group company of Rigaku Holdings Corporation (headquarters: Akishima, Tokyo; CEO: Jun Kawakami; hereinafter “Rigaku”) has won the Diana Nyyssonen Memorial Best Paper Award (hereinafter “the Award”) with a revolutionary, non-destructive method of discovering defects in 3D flash memory. The inspection and measurement technology (hereinafter “the Technology”) uses an ultra-high-resolution X-ray microscope.

The Award is conferred on the team that delivers the most compelling paper in the fields of measurement, inspection and process control at the SPIE Advanced Lithography + Patterning Conferences. These conferences report the latest research results on lithographic technologies applied in semiconductor manufacturing.

One issue occurring at 3D flash memory production sites is the difficulty of inspecting and measuring the shapes of embedded metal structures and extremely deep holes known as “memory holes."

The technology developed by the Rigaku team achieves ultra-high resolution by employing X-rays, whose detection limit is 1/10 or lower that of the best optical microscopes. In addition to revealing the extremely fine structures of the nanoscale, the technology enables non-destructive observation of devices formed on silicon substrates. The revolutionary nature of this solution is what persuaded the Conferences to confer the award.

Kazuhiko Omote, General Manager of X-ray Research Laboratory, one of the authors of the paper, states that, “By introducing equipment incorporating this technology, 3D flash memory worksites can expect to enjoy improved yields and optimized production processes. Rigaku targets implementation of the technology in this way in about two years’ time“.

Going forward, Rigaku aims to leverage this technology in pursuit of further innovations, such as application in inspection and measurement of conductance in the connective parts of multilayered devices.

Details of Award Announcement

Title: Non-Destructive Investigation for Metal Structure in 3D Flash Memory by an Ultra-High Resolution X-ray Microscope
URL: https://rigaku-holdings.com/pdf/Proc. of SPIE Vol. 12955 129551B.pdf

About the Rigaku Group

Since its establishment in 1951, the engineering professionals of the Rigaku group have been dedicated to benefiting society with leading-edge technologies, notably including its core fields of X-ray and thermal analysis. With a market presence in over 90 countries and some 2,000 employees from 9 global operations, Rigaku is a solution partner in industry and research analysis institutes. Our overseas sales ratio has reached approximately 70% while sustaining an exceptionally high market share in Japan. Together with our customers, we continue to develop and grow. As applications expand from semiconductors, electronic materials, batteries, environment, resources, energy, life science to other high-tech fields, Rigaku realizes innovations “To Improve Our World by Powering New Perspectives.”
For details, please visit rigaku-holdings.com/english
